BlueStorm Installation Guide, Connect Tech Inc.
16 Revision 0.08
Table 3: VHDCI-68 Female Pinouts for BlueStorm/LP (continued)
Pin
No.
Port
No.
RS-232
Signal
Signal
Direction
RS-422/485
Signal
Signal
Direction
47
6
RTS
output
RTS-
output
48
6
DSR
input
CTS-
input
49
6
RXD
input
TXD+
output
50
6
CTS
input
RTS+
output
51
5, 6 SG
signal gnd.
SR
signal ref.
52
7, 8
SG
signal gnd.
SR
signal ref.
53
7
TXD
output
TXD-
output
54
7
RI
input
CTS+
input
55
7
DCD
input
RXD+
input
56
7
DTR
output
RXD-
input
57
7
RTS
output
RTS-
output
58
7
DSR
input
CTS-
input
59
7
RXD
input
TXD+
output
60
7
CTS
input
RTS+
output
61
8
TXD
output
TXD-
output
62
8
RI
input
CTS+
input
63
8
DCD
input
RXD+
input
64
8
DTR
output
RXD-
input
65
8
RTS
output
RTS-
output
66
8
DSR
input
CTS-
input
67
8
RXD
input
TXD+
output
68
8
CTS
input
RTS+
output
Cable CBG009 and/or IOBG08BLV1will send the signals to eight DB-9 male connectors. See
for the DB-9 pinouts. Cable CBG026 will send the signals to eight DB-25 male
connectors. See
for the DB-25 pinout details.
