VCR and Cassette Information
[ Erase Protection (Record Ta^
Cassettes have a record tab to ensure that
recordings are not accidentally erased.
To prevent accidentat erasure,
break off the tab with a screwdriver
«à
iver. (“¿rr-
To record again, cover the
hole with cellophane tape.
Reset all VCR Memory Functions
Use when moving the VCR to a new location, or if a
mistake was made in the One Time VCR Setup section.
• Make sure a tape is not inserted in the VCR.
1) Turn VCR Power on.
2) Press and hold both PLAY and CHANNEL
A
on the
VCR for more than 5 seconds.
• The power will shut off.
3) Perform the One Time VCR Setup section on page 12.
D.S.T. (Daylight Saving Time)
Maximum Record/Playback Time
Only use tapes with the
IVtiSI mark
in this unit.
Tape Speed
Setting
Type of Video Cassette
T60
T120
T160
SP
(Standard Play)
1 Hour
2 Hours
2 Hours
40 Minutes
LP
(Long Play)
2 Hours
4 Hours
5 Hours
20 Minutes
SLP
(Super Lortg Play)
3 Hours
6 Hours
8 Hours
Your VCR can be set to automatically adjust the clock for
Daylight Saving Time. (Page 13.)
Spring (First Sunday in April)
When set to DST:ON, the VCR will automatically set the
clock ahead one hour.
Autumn (Last Sunday in October)
When set to DST:ON, the VCR will automatically set the
clock back one hour.
• If your area does not observe Daylight Saving Time,
select DST:OFF.
• Keep these time changes in mind when programming
the VCR for timer recordings.
Specifications
Head Cleaning
Your VCR will not normally require head cleaning,
however the heads may become clogged when playing
an old or darnaged tape.
Video Heads Sensor System
If head cleaning becomes
necessary, the VCR will display
the screen at right while playing
back a recorded signal.
To exit this screen, push PLAY
on the remote control or VCR.
VIDEO HEADS MAY
NEED CLEANING
PLEASE INSERT HEAD
CLEANING CASSETTE
OR REFER TO MANUAL
END:PLAY KEY
• Uso “dry" type head
cleaning cassette* only.
• Be sure to follow the cleaning tape instructions carefully.
Excessive use of a cleaning cassette can shorten head life.
• If using a head cleaning cassette does not solve the problem,
contact your nearest Factory Service Center or authorized
Service Center, {See page 32.)
• Cleaning cassette part No. NV-TCL30PT Is recommended.
Power Source:
Power Consumption:
Video Signal;
Video Recording System:
Audio Track:
Tuner:
Broadcast Channels:
CABLE Channels:
Operating Temperature:
Operating
Humidity:
Weight:
Dimensions:
120V AC, 60 Hz
Approx. 18 watts (Power on)
Approx. 4.1 watts (Power off)
EIA Standard NTSC color
4 rotary heads helical
scanning system
1 track (Normal)
VHF2-13, UHF 14-69
Midband A through I (14-22)
Superband J through W (23-36)
Hyperband AA-EEE (37-64)
Lowband A-5-A-1 (95-99)
Special CABLE channel 5A (01)
Ultraband 65-94, 100-125
4rF-104°F(5“CU0“C)
10%-75%
7.5 lbs. (3.4 kg)
14-15/16” (W)x 3-2/3" (H)x
12-3/16" (D)
380 (W)
X
93 (H)
X
310 (D) mm
Note: Designs and specifications are subject to change
without notice.
