Location of Controls
Remote Control Buttons
VCR--------------------
See pages 28, 29.
POWER-------------------------------
See pages 12,18,19, 27, 28, 29
VCR/TV -----------------------------------------
See pages 12, 17, 23, 29.
PLAY --------------- -----------------------------
See pages 16, 21,29.
SELECT UP
See pages 12-15,18,19, 22, 25-27, 30
REWIND/SEARCH ----------------
See pages 16, 20, 21.29.
SET/BACKSPACE
See pages 13,14,18,19, 26.
ACTION------------------------------------------
See pages 13-15, 22, 25, 26, 30,
PAUSE--------------------------------
See pages 16,17, 23, 29.
NUMBERED KEYS
See pages 14,17, 20, 27-29.
DISPLAY/ENTER
See pages 15, 17, 22, 29.
INDEX-----------------
See pages 20, 21.
SPEED ---------------
See pages 17, 29.
COUNTER RESET
See pages 22,29.
---------- ------------- TV
See pages 28, 29.
DSS/CABLE
See pages 26, 29.
------------------------------ INPUT
See pages 17, 23, 29.
FAST FORWARD/SEARCH
See pages 16, 20, 21, 29.
SET
See pages 12-15,18,19, 22, 25-27,30.
------------------------------------------------ STOP
See pages 14, 16, 17, 19,21,29.
SELECT DOWN
See pages 12-15,18,19, 22, 25-27, 30.
PROGRAM
See pages 18, 19, 27.
— RECORD/TIME
See pages 17,29.
--------------- SLOW
See pages 16, 29.
---------------------- ADD/DELETE
See pages 14,19, 26, 27.
CHANNEL UP/DOWN
(TRACKING UP/DOWN)
See pages 12-14,16,17, 23, 29.
VOLUME UP/DOWN
See page 29.
ZERO SEARCH/
1 MINUTE SKIP
See pages 22, 29.
Front View of the VCR
_ , PLAY
Cassette Com^rtment Seepages
See pages 16, 17, 23. .|g 2 ‘| 23 29
STOP/EJECT \ REWIND/SEARCH
Seepages \ See pages 16,19,20,21,29.
16 17,19,21,23,29. \ \ FAST FORWARD/
^ ^ SEARCH
See pages 16, 19, 20,
21,29.
RECORD/TIME
See pages
17, 19, 23,29, 30.
POWER
See pages
12, 18, 19, 27, 29.
CHANNEL UP/DOWN
TRACKING/V-LOCK
See pages 12,16,17, 23, 29
REMOTE
SENSOR
Multi Function Display
See pages 11,16-19, 23, 27.
VCR/TV Selector
See pages 12,17, 23, 29.
