VCR
Plus+ Setup
(continued)
^Important: If the remote control POWER, ACTION, PROG, CHA/V , INDEX, or ADD/DLT button does
not work when pressed, press the VCR button on the remote and try the button again.
In order for the VCR to read the VCR Plus+ code, some set up is required. A Guide (VCR Plus+) channel number
is assigned to each local broadcast and cable station. Because this number sometimes differs from the channel
your TV receives the station on, it is necessary to program the VCR with local channel information.
Complete this page only if Type B
connection method (pg.24) is used.
NOTE; Complete the steps on this page if your
cable box can be controlled with the VCR, or
your VCR hook-up resembles “B” on page 24.
Prepare a list like the example below.
This list will help you smoothly enter the information
needed in step “4" at right.
You will need the following to complete the list;
■ A line up of normal and/or cable stations you
receive along with the channel numbers your TV
receives them on. A cable channel line-up chart
is supplied by your cable company.
■ A list of Guide (VCR Plus+) channel numbers
■ assigned to the stations you receive. This list is
available in TV Guide and the TV listings found
in selected newspapers.
1
Make a chart with 3 columns like the example
below. In the left column, fill in the name or call
letters of the stations you receive.
2
In the middle column, fill in each station’s
assigned Guide (VCR Plus+) number found in
TV Guide, newspapers, etc.
3
In the right column, fill in the channel number
that your TV receives the station on from your
channel line-up.
EXAMPLE ONLY
Broadcast or
Cable
Station Name
Assigned
Guide
(VCR PIUS+)
channel no.
Channel
no. your TV
receives the
station on
HBO 33 15
Nickelodeon 38 20
CBS 04 04
\ FOX 11
Of; ^
VCR Pius+ Channel Setup
• Before you begin, complete the Channel Setup
Preparations below left.
Important Note:
If your VCR connection type changes from type A to B,
repeat steps 1~4 of page 25 and select VCR
>
CABLE/
DSS BOX r- TV or VCR ► TV before proceeding with
these steps.
1
Press ACTION* to display
the menu.
2
Press AT to select “SET UP
CHANNEL,** and then press
--------------- MENU ---------------
SET UP VCR
SET CLOCK
Е1Д1«1Д«!!Ш!ГП
IDIOMA / LANGUE : ENGL I SH
SELECT:* ▼ KEY
SET :► KEY
END ; ACT ION KEY
► to display the “SET UP CHANNEL" screen.
Press AT
to select “VCR
Plus-H CH SET UP,” and then
press ► to display the “VCR
Plus-«- CH SET UP” screen.
------ SET UP CHANNEL ------
ANTENNA : CABLE
AUTO SET
CABLE/DSS BOX SET U
^Bn™iBanEi
SELECT:* T KEY
SET :► KEY
END
: ACT I ON KEY
IMPORTANT NOTE:
For step “4,” use the list you prepared. You may leave
lines blank if you don’t receive that station, or if the
GUIDE CH number and the CABLE (or TV) CH numbers
are the same.
4
Press ► to move the shaded
area to the right side.
Then, press AT to change
CABLE or TV CH number.
Next, press A to set the number.
Now, press AT to continue.
Repeat this operation until the list
is complete.
VCR P(us+ CH SET UP
GUIDE CH CABLE CH
* Efl
02
SELECT
SET
END
* ▼ KEY
► KEY
ACTION KEY
VCR Hus+ CH SET UP
GU1 DE CH CABLECH
► 01 В
02 —
SELECT:* ▼ KEY
SET r* KEY
END : ACT ION KEY
To Enter More Programs
Press AT and ► to select the incorrect CABLE or TV CH
number. Then, press AT to change, or ADD/DLT to delete
the channel.
5
Press ACTION three times to exit
the VCR Plus-i- CH SET UP mode.
Make each entry within 5 minutes or the VCR will
leave this mode.
(NOTES)
Once local channels have been programmed, they will
stay in memory, even in the case of a power failure.
