Replacing the Roller Modules
4
Draw the paper feed roller module
toward you and remove it starting
with its left side.
5
Open the optional "Roller Exchange
Kit (KV-SS041), and take out the
paper feed roller module.
For supplies and accessories:
Call 1-800-346-4768 (U.S.A. only)
or your dealer.
6
Install the new paper feed roller
module with its gears on the right
side and its bearing into the guide
groove of the side chassis in the
scanner, and push down the lev
ers at both ends until they click
into position.
• Insert the paper feed roller module in
the scanner starting with its right
side, and follow the sequence of 0
through 0 for installation.
7
Close the front door.
• Push the front door down slowly until
it clicks into position.
