■ Using the Rubber Cushion (Optionai)
(If there is an existing Rear Support Bracket on the Fire Wall of Car.)
Cover Mounting Bolt (g) on the rear of the unit with Rubber Cushion (Optional), and mount it into exist­
ing Rear Support Bracket.
Rear Support Bracket
(existing on the car)
Rubber Cushion (Optional)
d) Mounting Bolt
\ 0 Mounting Collar
3. a) Piug the Power Connector
b) Install the Trim Plate
©Trim Plate
Power Connector
4. After installation reconnect the negative (-) battery terminal.
To Remove the Unit
a) Remove the removable face plate. (^ Page 18.)
b) Remove the trim plate © with a screwdriver as
shown in the figure.
c) Puli out the unit while pushing the lock lever using a screwdriver.
d) Remove the unit pulling with both hands.
Lock Lever
17
