Installation Guide
Preparation:
• Before installation check the radio operation with antenna and speakers.
• Disconnect the cable from the negative {-) battery terminal (see caution below).
Caution:
For installation to cars with trip or navigational computer, all electronic memory settings previously
registered in the computer will be lost when the battery terminal is disconnected. For this type of car,
battery could not be disconnected. Therefore, extra care should be taken to prevent short circuitting.
In dash installation
Installation Opening
In-dash installation can be done if the car’s dash­
board has an opening for this unit as shown in Fig. 1.
The car’s dashboard should have a thickness of
4.5mm-6mm in order to make the installation of the
unit.
182mm-
T
53mm
1
Fig. 1
Installation Precautions
This equipment, if possible, should be installed by a professional installer.
In case oif difficulty, please consult your nearest authorized Panasonic Service Center.
1. This system is to be used only in a 12-volt, DC battery system (car) with negative ground.
2. Follow the electrical connection ( p a g e 19) carefully. Failure to do so may result in damage to
the unit.
3. Connect the power lead after other connections are made.
4. Be sure to connect the YELLOW lead to positive terminal (+) of the battery to fuse block (BAT) ter­
minal.
5. Insulate all exposed wires to prevent short circuitting.
6. Secure all loose wires after installing the unit.
7. Please carefully read the operating and installation instructions of the respective equipment before
connecting it to this unit
□ Installation Hardware
No. Itenft Diagram Qty m Item Diagram Qty
®
Mounting Collar 1
0
Mounting Bolt (5 mm0) 1
Hex. Nut (5 mm0)
1
©
Power Connector 1
Rear Support Strap
1 Trim Plate 1
0 Tapping Screw
1
.
CQ-DP33EW
