Panasonic KX-G2200A - Manual (Page 3)

SPECIFICATIONS
• General
Number of Channels:..................................... All International, USA and Canadian channels
All Memory channels
10 Weather channels
Temperature range; ...................................... -20°C to +50'^C (~4°F to +122°F)
Channel spacing: .......................................... 25 KHz
Power Supply: .............................................. 13.8 Volts DC (±20%)
Antenna impedance;...................................... 50 ohms
Channel memory back up;............................. 5 years with an internal Lithium Battery
Size; ............................................................ 55mm (H) x140mm(W)x180mm (D)
(2 3/16” (H)x5 1/2" (W)x71/16” (D))
Weight; ........................................................ 950 g (2.09 tbs.)
Current:........................................................ receive standby: 500 mA
with full audio output; 1 A
transmit low output; 1.5 A
high output; 5 A
• Receiver
Frequency range;.......................................... 156.025 - 163.275 MHz
Sensitivity;.................................................... less than 0.3 /u.V for 12 dB SINAD
Squelch sensitivity;........................................ threshold; 0.12 juV
Audio output; ................................................ 4W at 10% distortion to 4 ohms speaker
Frequency stability;........................................ ±0.001%
• Transmitter
Frequency range;.......................................... 156.025 - 157.425 MHz
Maximum Deviation:...................................... ±5 KHz
RF output power:........................................... High 25 W, Low 1
W
Spurious & harmonics emission;..................... spurious emission; 65 dB below carrier
harmonics emission: 60 dB below carrier
Audio distortion: ............................................ less than 5%
Frequency stability;........................................ ±0.001%
OTHER INFORMATION
• Back up battery for memory
To retain the programmed channels in memory a built-in battery for back up is provided.
If the programmed channels are lost in the memory channel mode after turning your radio on,
the built-in battery must be replaced with new one at a Panasonic Servicentre.
NOTE: This special battery is NOT User Replaceable.
• Dead Spot
Transmission and reception may be difficult from some locations, due to outside influences.
If this happens, move to another location if possible.
- 2 -
