Optional Connections
Set-Top Box Connection to Dolby Digital AC-3 Decoder
Follow this diagram to connect the STB to a Dolby Digital AC-3 decoder.
Dolby Digital
AC-3 Decoder
r
DIGITAL
! 6-Channet Amplifier j [
audio
in
(AC-3)
i & Speakers i' 1
------------------------------------------------------------------- *
1
P jl
DOLBY DIGITAL AC-3 DECODER SETUP
Procedure
•
Connect Digital Audio cable from the Digital Audio Out connection on the STB to the Digital
Audio In connection on the Dolby Digital AC-3 decoder.
•
Follow directions in Getting Started section to connect the STB to a DTV-compatible TV,
