Panasonic OMNIVISION PV-M2737 - Manual (Page 25)

In order for the Combination VCR to read the VCR Plus+ code, some setup is required. A Guide (VCR Plus+) channel number
is assigned to each local broadcast and cable station. Because this number sometimes differs from the channel your TV
receives the station on, it is necessary to program the Combination VCR with local channel information.
VCR Plus+ Channel Setup
For Connection Type B (page 24) only
• Before you begin, complete the Channel Setup Preparations
below left.
Important Note:
If your Combination VCR Connection type changes, from Type A
to B, repeat step 4 of previous page, select “NO”.
Push MENU to
display the MAIN
MENU.
(Co
MAIN MENU
sia o
TV VCR pE
dE3 © n
CH CLOCK EXIT
SELECT:
A
T ► KEY
SET :MENU KEY
Push^W<\\>
to select “CH,”
and then push MENU to display
the SET UP CHANNEL screen.
Channel Setup Preparations
NOTE:
Complete the steps on this page if your Combination
VCR hook-up resembles
“B” on page 24.
Prepare a list like the example below.
This list will help you smoothly enter the
information needed in step “d” at right.
You will need the following to complete the list;
■ A line up of normal and/or cable stations you
receive along with the channel numbers your
TV receives them on. A cable channel line-up
chart is supplied by your cable company.
■ A list of Guide (VCR Plus+) channel numbers
assigned to the stations you receive. This list
is available in TV Guide and the TV listings
found only in selected newspapers.
1 Make a chart with 3 columns like the example
below. In the left column, fill in the name or
call letters of the stations you receive.
2 In the middle column, fill in each station’s
assigned Guide (VCR Plus-i-) number found in
TV Guide, newspapers, etc.
3 In the right column, fill in the channel number
that your TV receives the station on from your
channel line-up.
< EXAMPLE ONLY >
Push^ Tto
select “VCR
Plus-H CH SET
UP,” and then
push 0 to
display the “VCR
P\us+ CH SETUP” screen.
--- SET UP CHANNEL ---
ANTENNA SYSTEM : CATV
AUTO SET
CABLE BOX SET UP
SELECT
SET
END
i ▼ KEY
► KEY
MENU KEY
IMPORTANT NOTE:
For step “d”, use the list you prepared at left. You may leave
lines blank if you don’t receive that station, or if the GUIDE
CH number and the CATV (or TV) CH numbers are the same.
I Push [>to move
the shaded area
to the right side.
VCR PIUS+ CH SET UP
GUIDE CH CATV CH
ED
02
SELECT ; A ▼ KEY
SET :► KEY
END :MENU KEY Then, push A W
to change the CATV(or TV) CH number.
Next, push <|
to set the CATV(or TV) CH number.
Now, push A W
to continue. Repeat this operation until the list is
complete.
To Make Corrections
Push A TandE^to select the incorrect CATV or TV CH
number. Then, push A Tto change, or ADD/DLT to delete the
channel.
