Table 1
Type of
RG-59/U
RG-6U
RG'11/U RG-15/U
coaxial cable
(3C-2V)
(5C-2V)
{7C-2V) (10C-2V]
Recommended (ft)
825
1,650
1,980
2,640
maximum
cable lenght
(m)
250
500
600
800
3. Wiring precautions:
•
Do not bend coaxial cable into a curve whose radius
is smaller than 10 times the cables diameter.
•
Never staple the cable-not even with circular
staples. Mismatching will occur.
•
Never crush or pinch the cable.
All of these will change the impedance of the cable
and cause poor picture quality.
