Panasonic CT-3268S - Manual (Page 11)

Location of Controls Remote
(forCT-3268S)
Power Button
Press to turn ON or OFF.
TVAiideo Button
Press to select TV or one of
two Video Inputs, for the Main
Picture or the PIP frame (when
the PIP frame is displayed).
Volume Buttons
Press to adjust TV sound level.
Use with Channel buttons to
navigate in menus.
Keypad Buttons-------------------------
Press desired channel number to
randomly access any channel.
R-Tune (Rapid Tune) Button
Press to switch to the previous
channel.
VCR Function Buttons
Programmable to operate many
brands of VCR’s.
TVA/CR/CABLE Switch
This switch is used to select the
proper mode when programming
Remote Control Infrared codes or
operating the TV or external
equipment (VCR or Cable box).
PiP Move Button
Press to position PIP frame
to any corner of the Main
Picture (when PIP frame is
displayed).
PIP Freeze Button
Press to stop action in the Main
Picture or PIP frame (when the
PIP frame is displayed).
Mute Button
Press to mute sound. A second press
resumes sound. Press also to access
and delete Closed Caption.
Multi Button
Programmable to operate up to six
Remote Control Function buttons
simultaneously.
Channel Buttons
Press to select channels. Use with
Volume buttons to navigate in menus.
Action Button
Press to display Main Menu and
access or exit On Screen feature
and Adjustment Menus.
Recall Button
Press to display Time, status of Sleep
Timer, Channel, Video Mode, Channel
Caption (Station Identifier) and Audio
Mode.
Cable Power Button - Programmable
to operate selected CATV converter
boxes.
PIP (Picture In Picture) Button
Press to display the PIP frame, press
again to remove PIP frame.
PIP Swap Button
Press to interchange PIP frame with
Main Picture (when the PIP frame is
displayed).
PIP Size Button
Press to select size of PIP frame
(when the PIP frame is displayed).
EUR511001A
- 1 1 -
