Panasonic CQ-DFX777EW User Manual
Panasonic, Cq-dfx777ew
Attention! The text in this document has been recognized automatically. To view the original document, you can use the "Original mode".

DIGITAL AUDIO
CQ-DFX777EW
High Power CD Player / Receiver with
Changer Control
Specifications*
General
CD Player
Power Supply
12V DC (11V-16V),
Sampling Frequency
32 times over sampling
test voltage 14.4V, negative
DA Converter
MASH ■ Ibit 4-DAC system
ground
Error Correction System
Panasonic super decoding
Maximum Power Output
40Wx4ch, at 400Hz, Vol. MAX
algorithm
Power Output
14W>^4{D!N45 324, at 4i2)
Pick-Up Type
Astigma 3-beam
Tone Adjustment Range
Bass; ±12 dB at 100Hz
Light Source
Semiconductor laser
Treble: ±12 dB at 10kHz
Wavelength
780nm
Pre-Amp Output Voltage
2.0V (CD play; 1kHz 0 dB)
Frequency Response
20Hz-20,OOOHz,±1 dB
Output Impedance
6000
Signai/Noise Ratio
96 dB
Current Consumption
Less than 2.2A (CD play)
Total Harmonic Distortion
0.01% (1,000Hz)
Wow and Flutter
Below measurable limits
AM Radio
Channel Separation
75 dB
Frequency Range
531-1,602kHz
Usable Sensitivity
28dB/pV (25pV, S/N 20 dB)
Dimensions** (W^H^D)
7">'1-15/16’'’< 5-7/8
{178>«50x150 mm)
FM Stereo Radio
Weight**
3lbs. 5 oz (1.5kg)
Frequency Range
87.5-108.0MHz
Usable Sensitivity
6dB/pV(S/N 30dB)
Stereo Separation
42dB at 1,000Hz
* Specifications and the design are subject to, modification wit
notice, due to improvements in technology.
** Dimensions and Weight shown are approximate.
Panasonic’
© 1999 Matsushita Communication Industrial Co.,
Ltd, All rights reserved. Unauthorized copying and
distribution is a violation of law.
