uonneciions/mmai ьетир

(Ready to Play)

Please make al! cable or antenna connections before power on.

Connecting

For ANT./Cabie

Connect the cable from Antenna/Cabie
to the VHF/UHF terminal on the unit.

For DSS/Cabie Box

Connect the OUT jack on your cable
box to the VHF/UHF terminal on the unit

with a RF cable.

WARNING:

Overtightening “Nut type” RF coaxial cables

may damage jacks. Finger tighten only.

Initial Setup (Ready to Play)

Press COMBO on the remote for Combo mode.

UNIT (rear view)

Plug the unit power cord into AC wall

outlet.

Press POWER*

on the remote or unit.

The unit comes on and auto channel and

clock set starts. ____________________

If you use a cable box, turn

it on and set it to the Public
Broadcasting Service (PBS)
channel in your time гопе.

If you use a DSS receiver, It

must be turned off.

ri i Atrio 5—; ri'íoíiíiífflSéí;

iiK«2ÉÉÜi;4S.;;;

Settings are made automatically. When
setup is done, this screen appears.

................ :Ü58T,)0NV-

tSpriNe;;

.■ í CÓIilÍ4.ÉlBlSríV:b

if AUTO CLOCK SET IS INCOMPLETE screen

appears, set the clock using MANUAL CLOCK
SET procedure on next page.

; ■ ■UAuTC.iGf.LOCiri

•;:|F

i m

. is ijNv.òP.Pl E"

vir

Ж i=ìv

• Function buttons are inoperative during Initial

Setup.

• To remove a cassette during Auto Set, press

EJECT twice on the remote or STOP twice on

the unit. In this case, settings must be made

manually. (See page 10.)

• Depending on conditions, Auto Clock Set may

take longer than 30 minutes. If so, press STOP
to stop setup and perform settings manually.

(See page 10.)
