Specifications
CRT Size 21" CRT (20.0750.8 cm Viewable Image Size) Flat Square
Dot-pitch 0.25 mm (H : 0.218mm
/
V : 0.130mm
)
Phosphor RGB short persistence (Hi-EU RED)/Dark TINT
Surface treatment Anti-glare, anti-static, anti-reflective coating (New AGRAS coat)
Input signals Video signaling RGB analog
Signal level 0.7 Vp-p (without sync, signal), 1.0 Vp-p (with sync, signal)
Sync signal HA/ separation (TTL level), H/V composition (TTL level),
Sync-on-green
Horizontal Frequency Range Allowable Frequency Range: 30.0 kHz to 95.0 kHz
Vertical Frequency RangeAllowable Frequency Range: 50.0 Hz to 180.0 Hz
Preset mode 1 preset and 7 reservation (See page 16)
Video Maximum Pixel Clock 202.5 MHzltypj
Resolution 1600 dots(H) X 1200 lines (V)
/
75 Hz. FCC class B* + CISPR 22-B, max
1600 dots(H) X 1280 lines (V)
/
71 Hz Nl, FCC class A, max.
Viewable Image Size Factory preset
(H X V, Diagonal) Full scan (Typical)
1
5.43" X 11.57", 19.30" Diagonal
”
1
5.98" X 11.97", 20.00" Diagonal
“
Display Color Analog input, unlimited number of colors
“*
Connectors Signal 15-pin mini D-Sub connector (female pins), BNC x 5
Power supply CEE 22 type 3-pin connector
Input power 100 to 240VAC (50 or 60Hz)
Power consumption 145W typ.
/
< 15W stand-by, < 4W sleep mode (See page 14)
Controls Front Power ON/OFF, [U, H, B, H] keys
On screen display Contrast, Brightness, Size & Pos (Horizontal Positlon,Horizontal Size,
Vertical Position, Vertical Size), Geometry (V. Pincushion, Side Pincushion
Balance, Trapezoid, Parallelogram), Rotation (Tilt), Color Temp. (9300 K
+
8 MPCD, 7500K, 6500K, 5000K, User color adjustment), Recall, Video
Level select (0,7V/1,0V), Horizontal Moire, Vertical Moire, Language
select, OSD Position, Degauss, Signal, Input select, Monitor Self-Test
Tilt/swivel 13“ up, 4“ down, 90“ each to right and left
Dimensions (W x H x D) (19.9" X 19.2" X 20.4")
505 mm X 487 mm x 519 mm
Weight (monitor only) 27.5 kg (60.6 lb.)
Approvals UL1950, CSA 22.2 No.950.TUV/GS, NORDIC, DHHS, HC.
FCC Class B, IC-B, CE
/
CISPR 22-B(EN55022), VCCI Class 8,
MPR11, TCO ’92
/
NUTEK, IS09241-3 (Ergonomics)
/
-8 (Colors),
VESA DPMS, E nergy S tar *
Standard 1 detachable signal cable for VGA, SVGA.
1 detachable AC power supply cord.
Tilt & Swivel base attached.
Operating Instructions, Warranty card
Environmental conditions
Operating Temperature
Humidity
Altitude
0to40“C (32 to104“F)
5 to 90% (no condensation)
10,000 ft
Storage Temperature
Humidity
Altitude
-20 to -^60“C (-4to140“F)
5 to 90% (no condensation)
40,000 ft
Windows*95 Plug & Play VESA DDC1/2B meets Winodwsi*95 Plug & Play Requirements
Note:
•The on-screen image may flicker if the display is operated with the Vertical freq. under 60 Hz .
*This monitor may only be used in a commerciaf or industrial environment at resolutions above 1,600 x 1,200 75Hz.
“Section on signal timing used, see page 15.
“‘Number of colors depends on the Video Board used, memory installed, and RAMDAC
(Random Access Memory Digital to Analog Converter).
Specifications and design are subject to change without notice.
This product may be subject to export control regulations.
Weight and dimensions shown are approximate.
