USER’S MANUAL
Audio:
if your TV set is equipped with Dolby
Digital and/or MPEG audio decoding
capability, you may connect the
Digital Audio output by Optical or
Coaxial RCA socket on your receiver
to TV Digital Audio input Optical or
Coaxial socket. (Refer to D and E)
You nnay also connect the digital
audio output to your A/V receiver
assuming it is capable of decoding
Dolby Digital /MPEG digital audio
stream.
If your TV set and/or A/V receiver
does not support Dolby Digital/MPEG
decoding, you need to connect L/R
Audio output RCA sockets on your
receiver to stereo l_/R Audio inputs of
TV set and/or A/V receiver. (Refer to
F). If your /W receiver supports
Dolby Pro Logic decoder, you can
switch ON "Downmix-Surround"
function.
Note: We suggest you to set volume
to maximum when recording the
program.
4.2 Switches for Video Output Mode Selection
Table 1. Display Output Configuration Table
(1)
sw
(2)
YPbPr
RGB
Monitor*
CVBS
S-Video
A A 1080i (1125) lOSOi (1125)
A B 576P 1152i
B A o76i PAL
6 B lOeOi (1250) 1080i(1250)
—
'Only one of RGB and Monitor output can be used at the same time
The display output table has four modes, SW1 and SW2 on the rear panel are for
mode selection.
