USER’S MANUAL
-ji-
Signal Indicator (LED): When a signal of a channel is successfully acquired the
yellow LED will light up.
2.2 Rear Panel
o
\yp •IVa ^^'/4
<^. 4 ;
iVciLi'<'i
AcMmow A
HP IN
HP OUT
_cra._
•• t
—... iMt Ml
•«» Mi M'jMmn
AC Power Mains: (100 - 250V'-; 50/60 Hz), typical 15W and max. 33W.
RF In: For connection to cable from outdoor terrestrial antenna.
RF Out: For connection to your TV antenna IN or VCR RF IN.
S-Video: Y/C component video lor connection to TV.
CVBS: Two composite video outputs for connection to TV. VCR or other /VV
receiver.
AUDIO; Two sets stereo audio outputs for connection to TV, VCR or other A/V
receiver.
YPbPr: Y/Pb/Pr component video for connection to TV.
RGB: R/G/B/HS/VS component video for connection to TV or monitor.
Coaxial: Digital Audio output by coaxial.
Optical: Digital Audio output by optical.
Serial Port (RS232); For system maintenance.
Monitor: R/G/B video by D-sub socket for display with such connector interface.
SW1/SW2: Switches for video output mode selection. Selection options are listed in
the table.
2.3 Box Contents
The box that carries your Receiver should also contain the following items:
• Remote Controller
• Two batteries (AAAM Size)
• RCA video cables (one yellow/ white/ red, the other red/ green/ blue)
• User’s Manual
3 The Remote Controller
3.1 Preparing the Remote Controller
• Remove the cover of the battery compartment (on the back of the handset)
