USER'S MANUAL

Technical Specifications

Terrestrial

ino'Jt ?roauoncv

VHF. UHF Band

Tuner/Demodulator

Siandatd

DVB-T (ETSI 300 744)

Channel Bandwidth

7MHz, Australian Channel

COFDM System

2K. 8K carrier

Hierarchical supported

Demodulaiion Ivne

QPSK. I6QAW. 64QAM

Guard Interval

1/32,1/16,1/8, 1/4 active

symbol duration

FEC

1/2, 2/3, 3/4, 5/6, 7/8

System

CPU

32-bil RISC

Transport

DVB Demultiplexor

Flash memory

4 MB

System memory

4 MB

EEPROM

32 K8

Video

Standard

MPEG-1 ISO/IEC 11172-2 and
MPEG-2 MP(i)ML and MPISO/IEC 13818-2

Video Memory SDRAM

Up to 1G MB

Field / Frame rale

SO/25 Hz

HD/SD, Interiaced/progressive output

mode supported

Aspect Ratio

1080i(112b)/5/6P/5/6i/

1080i{1250)

4:3, 16:9 and Letter box

supported

Audio

Standard

MPEG-1 ISO/IEC 11172-3 layer

1 and layer II /

MPEQ-2 ISO/IEC 13818-3
Dolby Diqltal AC-3

Samplinq rate

32.44.1.48 and 96 KHz

Dinilal Audio Output format

1EC-60958/1EC6I937

Rear panel Interface

RF input connector / Loop through

Output

lEC type 75 ohm

CVBS/ Stereo Output

2 sets of RCA connectors

Y/C output

S-VHS

Y/Pb/Pr component video

RCA connectors

R/G/B/HS/VS

RCA connectors
DB-15iFemale)

Diaital Audio SFDIF

Coaxial / Optical

Serial port
Mode Selection Switches

RS-232 iFemale, DB-9)
SW1.SW2

User interface

Front panel

8 Keypads, 7-segment (4 digits)

display and 3 LED indicators

IR Sensor

Power requirements

Mains input voltaqe

100-250VAC--

Mains input frequency
Power consumption

50/fi0 H2

Normal operation 15W

Standby mode 5W max.
Max. 33W

Environmental Condition

Operating Temperature

32^K“108'F (0-40'C)

Dimension (WxDxH)

Weight

365 X 250 X 60 (mm)

2.45 kg
