Appendix
7-36
EFIS-D10A
Installation
Guide
Appendix G: Weights
Add
ow
that aff
the plane. The following are the weights of the
EFIS-D10A and associated Dynon-supplied sensors.
EFIS-D10A ........................................................................................................1 lb 9 oz (0.709 kg)
EFIS-D10A + battery.......................................................................................1 lb 15 oz (0.879 kg)
EFIS 25-pin wiring harness ...................................................................................11.2 oz (0.32 kg)
EDC-D10A ............................................................................................................3.6 oz (0.102 kg)
EFIS OAT ................................................................................................................3.2 oz (0.08 kg)
Heated AOA/Pitot Probe & Heater Controller ......................................................11.2 oz (0.32 kg)
Unheated AOA/Pitot Probe......................................................................................5.6 oz (0.16 kg)
Appendix H: EFIS-D10A Specifications
ing any new instrument to an aircraft requires the installer to be aware of its weight and h
ects the overall weight and balance of
Mechanical
Fits into standard 3 1/8” panel hole
Optional flush mount bracket available
Operating
-22° to 122° F (-30° to 50° C)
Temperature
Power
Power:
8 watts typical; 13 watts maximum
Voltage:
10 - 30 Vdc
Connections
Wiring: DB25
male
connector
Screen
Backlight:
450 nits
Size:
3.8” diagonal (96 mm)
Resolution:
320 x 240 color pixels
Type:
AMLCD, TFT (Thin Film Transistor)
Inputs/Outputs
1 - AOA Audio Alarm
1 - RS-232 bidirectional PC communication
1 - RS-232 data inputs (GPS, SL30, etc.)
1 - RS-232 serial encoder output
1 - Dynon Smart Avionics Bus (DSAB) multidrop
