Dynon Avionics EFIS-D10A Pilots Users Guide User Manual
Page 49

EFIS Operation
5-16
EFIS-D10A Pilot’s User Guide
when you marked the record. For information about retrieving data and reading the file produced, please see the help file
included in the Dynon Product Support Program (version 5.0 and higher).
The EFIS-D10A has a limited amount non-volatile internal storage for the data log. With a 1-second recording interval,
at least 2 hours of cumulative data can be recorded; with a 10-second interval, at least 20 hours; with a 30-second
interval, at least 60 hours, and with a 60-second interval, at least 120 hours. When the EFIS-D10A internal storage fills
up, new records overwrite the oldest records. To delete the records in internal storage, select ERASE LOG, ERASE
MIN/MAX LOG, or ERASE SNAPSHOT LOG (only available on certain units).
The data format and connection settings for the internally-recorded data are described in the Help Files of the Dynon
Support Program.
