EFIS Operation
without auto-dim. The system records the new set level as the desired brightness, and auto-adjusts around the
new set point.
TIMER – Setting and using a timer
Enter the EFIS > TIMER menu. In the value setting box, the
DOWN or UP label is displayed, depending on which timer t
is currently selected. The currently running timer is displa
the Times/Aux Page, as described on page
ype
yed on
4-10. Use the
following points as you work with the timer.
The UP/DN button toggles the menu and timer between an up timer and a down timer. When switching to an up
timer, the timer set value resets, allowing the up timer to count up from 0:00:00.
To reset the timer, press the UP/DN button twice.
To start the timer, press START. Once started, the button’s label changes to STOP. To stop the timer, press
STOP.
To set the down timer, press HOUR, MIN, and SEC to adjust the timer to the desired value.
You may not have an up timer and a down timer running at the same time.
Multiple Dynon products connected via a DSAB network share one timer. Starting, stopping, or configuring the
timer on one instrument causes all other instruments to reflect the change.
5-14
EFIS-D10A Pilot’s User Guide
