EFIS Operation
5-8
EFIS-D10A Pilot’s User Guide
SHOW/HIDE DISPLAY ITEMS
In the EFIS > SETUP > CLUTTR menu, you can turn on or off almost every item displayed on the EFIS page. As with
all other menu items, these options are abbreviated to commands containing 6 letters or fewer. Pressing a button
corresponding to one of these options turns the respective onscreen item on or off. The following table summarizes the
display item abbreviations and their function.
Abbreviation
Display Item
Function
ALTBAR
Altimeter Bar
Toggles the display of the graphical altitude tape.
ALTDIG Altimeter
Digital
Toggles
the
display of the digital altitude window.
IASBAR
Indicated Airspeed Bar
Toggles the display of the graphical airspeed tape.
IASDIG
Indicated Airspeed Digital
Toggles the display of the digital airspeed window.
HDG
Heading
Toggles the display of the heading tape and digital display.
BALL
Slip/skid Ball
Toggles the display of the slip/skid ball and associated center markers.
TURNRT
Turn Rate
Toggles the display of the turn rate indicator and associated scale markers.
AOABAR AOA
Bar
Toggles the display of the angle of attack indicator. The AOA indicator requires the
use of a Dynon heated or unheated AOA probe.
CLOCK Clock
Toggles the display of the clock. Setting Zulu/local and 12/24 hour time is done in
the EFIS > SETUP > CLOCK menu.
BARO Altimeter
Setting
Toggles the display of the current altimeter setting (also known as the Kollsman
setting). This display is not required to adjust the altimeter setting. While in the
EFIS > BARO menu, a separate value-setting box appears, allowing adjustments to
be made.
