Steps:
1. Enter the Alarm setting interface.
Menu> Configuration> Alarm
Figure 5.20 Alarm Settings
2. Click Alarm Input tab.
Figure 5.21 Alarm Settings- Alarm Input
1) Select Alarm Input No. and configure alarm parameters.
2) Choose N.O (normally open) or N.C (normally closed) for alarm type.
3) Check checkbox to enable the alarm input.
4) Click to set the handling method.
Figure 5.22 Alarm Handling
5) Choose the alarm triggered recording/capture channel.
6) Check the checkbox to select channel.
7) Click Apply to save settings.
8) Click OK to back to the upper level menu.
56
