EXITING THE SETUP MENU
1. Power off the indicator.
2. Move the slide switch on the rear cover back to the left.
3. Power on the indicator. The display will go through a digit check, then settle into Normal
Operating mode. All front panel keys will now return to their normal mode of operation.
SETUP MENU DESCRIPTIONS
List and detailed descriptions of the items within the setup screens. Factory-set defaults are shown in
bold with a checkmark (
√).
Note: Most “F” menu items configure the indicator to the attached load cell and are entered by a
qualified instrumentation technician. These parameters do not appear in this manual. Do not
change these parameters, or the indicator may not function properly or may report highly
inaccurate readings!
NAME/CODE DESCRIPTION CODE/VALUE
F1
This item is for configuration by a qualified load cell indicator
technician. Do not change this value or the instrument readings may
be in error. 500 1,000
1,500 2,000
2,500 3,000
4,000 5,000
√
6,000 8,000
10,000 12,000
20,000 30,000
40,000 50,000
F2
This item is for configuration by a qualified load cell indicator
technician. Do not alter this value or the instrument readings may be
in error. 25 50
75
√ 100
150 200
F3
This item is for configuration by a qualified load cell indicator
technician. Do not alter this value or the instrument may respond
unpredictably. 0d
0.5d
√
1d
3d
5d
F4
Zero Range Selects the range within which the scale may be zeroed. Note that the
indicator must be in standstill to zero the scale. 100%
√
1.9%
FI-80 LCD extras:
2%
20%
F5
Motion Band Defines ‘motion’ in number of divisions of change between the
present display update and the previous display. If motion has been
detected within the prior two seconds, the Print and Zero commands
are disabled.
If a stable reading is not needed for printing or zeroing in your
application, set this value at its highest number.
1d
√
3d
5d
10d
FI-80 LCD extras:
0.25d 15d
20d 30d
40d 50d
