Model 2345 User Manual 3-7
Table 7. Trap Configuration Options
Trap When enabled, sends a Trap if. . .
Active Link/Modem The active link fails; the remote device goes on- or offline; or redundancy
switches between primary and secondary
Inactive Link/Modem The inactive link fails or the redundant local or remote device goes on- or
offline
Configuration The 2345 is set up incorrectly
Diagnostic Loopback is enabled or disabled
Authentication An unauthorized host attempts SNMP access to the 2345
Power/Fan Malfunction The power supply or fan fails
Cold Start The 2345 is reset by a power failure or forced reset
Alarm Input The 2345 received an alarm (standalone only)
Use the Alarm Output Configuration screen to view the current configuration and to enable or disable
alarms for the 2345. For a list of events that trigger alarms, see Table 7. To set up the alarms, follow
these steps:
1. At the System Configuration menu, type 3, "Alarm Configuration," and press .
2. At the Trap Configuration screen, type the number for a trap and press . See Table 8.
3. Press to cycle to Enabled or Disabled and press .
4. To return to the System Configuration menu, press .
These selections do not affect how the CIM Major and Minor LEDs report alarms.
Table 8. Alarm Configuration Options
Alarm When enabled, sends an alarm if. . .
Active Composite Link The fiber link fails (active signal in a redundant configuration)
Electrical Loss of Signal The electrical input signal fails
Electrical Yellow/Blue/Red Loss of sync, remote fault, or AIS (can be All 1s or Alarm Indication
Signal) occurs
Configuration The 2345 is set up incorrectly or the local and remote software versions do
not match
Power Supply The power supply or fan fails
Power-On Self Test Self test fails at power-up
Inactive Composite Link The inactive fiber link fails (redundant configuration, only)
