Model 2345 User Manual 2-1
Chapter 2
Hardware Installation and Functions
You can install the 2345 in a UCS 1000 or 1001 or place a standalone 2345 in a flat, secure location.
Before starting to install the 2345 in a chassis, make sure the chassis is installed and its User Manual
is available for reference. If the system includes an optional DMM and CIM(s), make sure these are
available:
• Serial cable (required to connect to a VT100 type terminal or PC)
• VT100 type terminal or PC to run the User Interface Manager software
• The DMM and CIM manuals
Setup and Installation
Follow these guidelines to determine which slot(s) can hold the 2345:
• You can install the 2345 in a UCS 1000 in any slot except 0 ( reserved for the DMM and CIM) or
the power supply slot(s).
• You can install the 2345 in a UCS 1001 in either slot.
• If this is a redundant pair of 2345s, plan to install the primary modem in an odd-numbered slot
and install the secondary modem in the next higher-numbered slot, such as slots 3 (primary) and 4
(secondary) or in a UCS 1001, left (primary) and right (secondary).
1. Unpack and inspect all components. Save the shipping carton and packing materials in case you
need to return the equipment to the manufacturer. Appendix A provides information for Return
Material Authorization (RMA).
2. If this is a standalone 2345, remove four screws from the back panel and slide the board part of
the way out to access the switch and jumpers.
3. Set jumpers as needed for line buildout (LBO), loopback, and pulse width ; see Table 1 and
Figure 3.
Table 1. Jumper Settings
Jumper Position Description
W2/W3 W2 Not Used
W3 LBO more than 300 ft (90 m)
Off LBO 300 ft (90 m) or less
W4/W5 W4 Allows software control of loopback; default
W5 Not used
Off Sets loopback
W6/W7 W6 Normal pulse (NP); default
W7 Wide pulse (WP)
