3240S Fiber-Optic Multiplexer 5-3
Table 11. T1 RJ-48 DCE to DCE Roll-Over Cable
Pin Signal Pin Signal
1 Out 4 In
2 Out 5 In
4 In 1 Out
5 In 2 Out
3, 6, 7, 8 Not used
3240S Models
Model Description
Base Unit Options
3240-BU-01-x-S 850 nm, MM, 15 dB, LED, ST
3240-BU-21-x-S 850 nm, MM, 15 dB, redundant LED, ST
3240-BU-16-x-S 1310 nm, SM/MM, 13 dB *, Laser, ST
3240-BU-36-x-S 1310 nm, SM/MM, 13 dB *, Redundant Laser, ST
3240-BU-17-x-S 1310 nm, SM/MM, 13 dB *, Laser, FC/PC
3240-BU-37-x-S 1310 nm, SM/MM, 13 dB *, Redundant Laser, FC/PC
3240-BU-11-x-S 1310 nm, SM/MM, 23 dB *, Laser, ST
3240-BU-31-x-S 1310 nm, SM/MM, 23 dB *, Redundant Laser, ST
3240-BU-13-x-S 1310 nm, SM/MM, 23 dB *, Laser, FC/PC
3240-BU-33-x-S 1310 nm, SM/MM, 23 dB *, Redundant Laser, FC/PC
3240-BU-12-x-S 1550 nm, SM, 23 dB, Laser, ST
3240-BU-32-x-S 1550 nm, SM, 23 dB, Redundant Laser, ST
3240-BU-14-x-S 1550 nm, SM, 23 dB, Laser, FC/PC
3240-BU-34-x-S 1550 nm, SM, 23 dB, Redundant Laser, FC/PC
x, Power Option: 1: -90/264 VAC Autoranging
4: -48 VDC
7: -90/264 VAC/Redundant
9: -48 VDC/Redundant
10: -90/264 VAC/-48 VDC Redundant
