Performance Specifications Performance Specifications
76 77 March 27, 1998 006-18081-0000 006-18081-0000 March 27, 1998
Go-Around Pitch Up Command Pitch to 750 fpm Climb
Alt Sel Engage Range 0 to 55,000 Ft.
Engage Vert Spd Limit Function of Vert. Speed
Max “G” During Capture
± 0.1G
Alt (Hold) Engage Range -1,000 to 20,000 Ft.
Engage Vert Spd Limit ± 2,000 Ft/Min
Accuracy ± 40 Ft*
Pitch Rate Limit 0.1G Vert Accel
IAS (Hold) Engage Range 50 KIAS to V
NE
Accuracy ± 3 Kts
Pitch Rate Limit 0.1G Vert Accel
VS (Vert Spd) Engage Range +10,000/-15,000 Ft/Min
Accuracy ± 100 Ft/Min*
Select Range ± 3,500 Ft/Min
Pitch Rate Limit 0.1G Vert Accel
Flight Director Pitch Command Limit +15 Deg/ -10 Deg
Roll Command Limit ± 25 Deg
Autopilot Pitch Engage Limit +25 Deg/ -20 Deg
Roll Engage Limit ± 25 Deg
SCAS Pitch Engage Limit None
Roll Engage Limit None
All accuracy specifications are based on aircraft operations in smooth air.
* Indicates altitude below 9,000 Ft. MSL.
Mode Parameter KFC 500 Value
Attitude Hold Pitch Command Profile 0.1G or 2 Deg/Sec
Pitch Hold Accuracy ± .3 Deg Smooth Air
Roll Angle Limit 25 Deg
Roll Command Rate Limit 12 Deg/Sec
Roll Hold Accuracy ± 1 Deg
Heading Hold Roll Angle Limit 10, 15, 20, or 25 Deg
(Pilot Selectable)
Roll Command Rate Limit 7 Deg/Sec
Accuracy ± 1 Deg
NAV Beam Intercept Angle All Angle
Roll Angle Limit 10, 15, 20, or 25 Deg
(Pilot Selectable)
(VOR Capt) Capture Point Function of DME,
Deviation, Dev Rate
& Course Error
Roll Command Limit 4 Deg/Sec
VOR Track Crosswind Correction Up To 30 Deg
(Over Station) Course Change Up To 90 Deg
Approach Beam Intercept Angle Up to 105 Deg Front
Course
(LOC Capture) Roll Angle Limit 20 Deg
Roll Command Rate Limit 10 Deg/Sec
Capture Point Function of Deviation,
Dev Rate & Course Error
(LOC Track) Roll Angle Limit 10 Deg
Cross Wind Correction Up To 30 Deg
Gain Programming Function of Rad Alt or
Time and TAS
GS Capture Point Function of Deviation,
Dev Rate
GS Damping Pitch Att, TAS, & Vert Acc.
0.25G
Gain Programming Function of Rad Alt or
Time and TAS
Mode Parameter KFC 500 Value
