Belt Drives TF-2000 User Manual
Page 5
14. Install clutch adjustment screw and adjust clutch as necessary. Refer to
and tighten after clutch is
adjusted. (Fig. 19)
Fig. 19
15. Install rear pulley cover. (Fig. 20)
Fig. 20
NOTE: THIS UNIT WAS DESIGNED USING A STOCK HARLEY-DAVIDSON MOTORCYCLE AND
MAY NEED EXTRA CARE FOR PROPER FITMENT. REFER TO WARRANTY PAGE OF INSTALLATION GUIDE.
For installation of the TF-2000 follow instructions above except for # 13 & 14. Refer to the alignment procedure
page for final installation of the outside bearing support.
5
