INSTALLATION FOR BALL BEARING CHAIN DRIVE
BDL Ball Bearing Clutch Basket
Fits 1998 to 2006 Big Twin
BDL Ball Bearing pressure plate with special diaphragm
and retainer
BDL Ball Bearing chain drive assembly
Install clutch basket on to transmission main shaft, install 3-.078" steels in first then alternate fiber, steel and ending
with a fiber. (Clutch pack is 8-.078" steels and 6 fibers)
Place diaphragm over ball bearings on pressure plate, place retainer with beveled side down over diaphragm and
install the 4 shoulder bolts through retainer into clutch hub. Be sure that bolt holes in retainer line up with the
rounded holes in diaphragm for proper fitment.
Adjust clutch as usual with special adjustment screw supplied with kit.
