Clarke ® American Sanders FloorCrafter Operator's Manual Page 69
Floorcrafter Belt Sander
Belt Tensioner Assembly Parts List #4 6/02
Ref. No Part No. Description Qty
1 Ref. Shaft, Guide Roller 2
2 Ref. Bearing 4
3 Ref. Roller Guide 2
4 920208 Nut, Hex ¼-20 3
5 60391A Bolt, Shoulder 2
6 60393A Lever, Draw 1
7 920296 Nut, 10-24 3
8 747380 Ring, Roller, Retaining 2
9 902567 Bearing, Ball 3
10 67201B Roller, Tension 1
11 60395A Screw, Link, Retaining 2
12 60396A Pin, Roller Shaft 1
13 51211A E-Ring 4
14 80140A Washer 2
15 60383A Shaft, Tension Roller 1
16 699202 Wire Tie 1
17 60381A Adjuster, Tracking 1
18 20018A Carriage, Tension Roller 1
19 60382A Link, Draw 2
20 81303A Nut, Hex Jam, ¼-28 1
21 81217A Nut, ¼-20 3
22 60379A Spring 1
23 925546 Pin, Roll 2
24 962822 Screw, ¼-20 x 5 /
8
1
25 51216A Rod, End, Female 2
26 962508 Screw, ¼-20 x 3 /
4
1
27 60906A Block, Wear 1
28 87007A Washer 1
29 20020A Support, Tensioner 1
30 80020A Bolt, Shoulder 1
31 51221A Link, Connecting 1
32 51099A Knob, Release 1
33 80139A Screw, ¼-20 x 7 /
8
1
34 60364A Lever, Tension Relief 1
35 962165 Screw, 10-24 x 3 /
16
1
36 51277A Ring, Retaining 1
37 87052A Washer, Flat, Nylon 2
38 10247A Cam, Release 1
39 30087A Boot, Belt Tensioning 1
40 14704A Guide Roller Assembly 2
