Clarke ® American Sanders Operator's Manual (EN) - Floorcrafter - 5 -
MODEL 07104A 07111A 07117A
Electrical 230~, 60Hz 230V~, 50Hz 230V~, 50Hz 230~, 50Hz
Requirements 15.7 A, 3.7 kW 11.8 A, 3.0 kW 12.0 A, 3.0 kW 12.0 A, 3.0 kW
Sound Emisson 93.0 dB(A) 96.2 dB(A) 96.2 dB(A) 96.2 dB(A)
(Lpm)
Vibration <.15 in/s 2.88 m/s 2 rms 2.88 m/s 2 rms 2.88 m/s 2 rms
Motor 4 Hp Induction 2.2 kW Induction 2.2 kW Induction 2.2 kW Induction
Contact Wheel Rate 2450 rpm 2042 rpm 2042 rpm 2042 rpm
Abrasive Rate 4500 ft/min 3750 ft/min 1143 m/min 1143 m/min
Abrasive Size 29½" x 7 7 /
8
" 29½" x 7 7 /
8
" 750mm x 200mm 750mm x 200mm
Fan Flow Rate 234 CFM 195 CFM 92 liters/s 92 liters/s
Drum Settings 80 lbs., 70lbs., 60 lbs. 80 lbs., 70lbs., 60 lbs. 36 kg, 32 kg, 27 kg 36 kg, 32 kg, 27 kg
Overload Protection Magnetic Circuit Magnetic Circuit 13 A Fuse Thermal Circuit
Breaker Breaker Breaker
Electrical Cable 50', 10-3 SJO 100', 12-3 SJO 15m HO7RN IEC309 16A-6H
LP-20P Plug AU2-15P Plug 3 x 1.5mm 2 Inlet and Connector
UK1-13P Plug
Operating Controls Adjustable Lever/Grip Adjustable Lever/Grip Adjustable Lever/Grip Adjustable Lever/Grip
Leveling Controls Externally Adjustable Externally Adjustable Externally Adjustable Externally Adjustable
Operating Wheels 80 Durometer 80 Durometer 80 Durometer 80 Durometer
Clear Urethane Clear Urethane Clear Urethane Clear Urethane
Weight 204 lbs. 204 lbs. 94 kg 93 kg
Dimensions 35 x 13 3 /
4
x 38 3 /
4
35 x 13 3 /
4
x 38 3 /
4
89cm x 35cm x 98cm 89cm x 35cm x 98cm
Introduction and Machine Specifications
CAUTION: Your equipment may be inappropriate on some installations. Some softer
woods used in flooring cannot support the pressure created by hard wheels.
Always consult with the flooring manufacturer on the proper installation, prepa-
ration, and finishing of their product. Determine suitability of your equipment in
preparing the product.
English Correct Disposal of This Product (Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European countries with separate
collection systems)
This marking shown on the product or its literature, indicates that it should not be disposed with
other household wastes at the end of its working life. To prevent possible harm to the
environment or human health from uncontrolled waste disposal, please separate this from other
types of wastes and recycle it responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their
local government office, for details of where and how they can take this item for environmentally
safe recycling.
Business users should contact their supplier and check the terms and conditions of the purchase
contract. This product should not be mixed with other commercial wastes for disposal.
