Clarke
®
American Sanders
FloorCrafter Operator's Manual
Page 65
Ref No. Part No
Description
Qty
1
42200A
Cord Set
1
40010A
Cable Asm. AU2-15P
1
40673A*
Cable Asm. UK1-13P
1
2
53538A
Rod, End
3
/
8
-24 L.H.
1
3
60387A
Rod, Control
1
4
920204
Nut,
3
/
8
-24 Hex Jam
1
5
80035B
Bolt, Shoulder
3
/
8
x1¼
1
6
53537A
Rod, End,
3
/
8
-24 R.H.
1
7
898203
Spacer, Rod End
1
8
80155A
Bolt, Shoulder ½ x
5
/
8
1
9
962727
Screw, 8-32 x ½
3
962727
Screw, 8-32 x ½
7*
10
80132A
Screw, ¼-20 x ¾
2
11
43501A
Inlet, Flanged
1
12
920110
Nut, Lk
5
/
16
-18
1
13
85313C
Screw, 6-32 x
3
/
8
Pan Hd
4
14
25601A
Lever, Control
1
15
980607
Washer, #6 Tooth Pltd.
4
16
20016A
Control Housing
1
17
48900A
Wire Assembly
1
18
64405A
Handle, Steering
1
19
41411A
Circuit Breaker, 30 Amp
1
20
81109A
Nut, Hex, Elastic, Lock, 8-32
1
21
21904C
Clamp, Steering Handle
1
22
85818A
Screw,
5
/
16
-18 x 2½ Hx Hd
1
23
49023A
Wire, Assembly
1
24
10155A
Assy, Cordholder
1
25
51220A
Bumper, Plastic
1
26
85613A
Screw, 8-32 x
7
/
8
1
27
980982
Washer, #10 SAE, Flat Hd
1
28
81112A
Nut, Lk.,
5
/
16
-18
1
29
80026A
Bolt, Shoulder,
3
/
8
x½
1
30
87619A
Washer, Flat, .63 x .38 x .03
1
31
85517A
Screw, 10-24 x ½
10
32
980022
Washer, Wave
2
33
87618A
Washer, Flat
1
34
60372A
Arm, Cord
1
35
980699
Washer
2
36
51074A
Clamp, Cable
2
37
60374A
Clamp, Retainer
2
38
41917A
Cord, Interconnecting
1
39
10145A
Mount, Handle Control
1
40
962288
Screw,
3
/
8
-16 x 1
4
41
45608A
Plug (for 42200A)
1
40024A
Plug (for 40010A)
1
45609A
Plug (for 40673A)
1
42
41706A
Connector
1
40039A*
Connector (for 40673A)
1
43
40674A*
Cover Switch
1
44
920065*
Nut, #8
7
45
40675A*
Cover Inlet
1
*
NOTE: used on machine model 07117A only.
FloorCrafter Belt Sander
Handle Control Assembly Parts List #2 1/04
