Clarke ® American Sanders FloorCrafter Operator's Manual Page 63
FloorCrafter Belt Sander
Main Assembly Parts List #1 1/04
Ref No. Part No Description Qty
1 60342A Seal, Felt 1
2 10142A Asm., Dust Tube Elbow 1
3 10144A Asm., Tube, Dust 1
4 920342 Nut, 3 /
8
-16 Lock 1
5 20022A Mainframe 1
6 81202A Nut, 7 /
16
-14 L.H. 1
7 60476A Pin, Motor Mount 2
8 68010A Stud, Idler Arm 1
9 60414A Arm, Idler 1
10 67875A Spacer 1
11 57801A Ring, Retaining 1
12 902619 Bearing 1
13 81108A Nut, Lock 3 /
8
-24 1
14 66170A Pulley, Idler 1
15 962216 Screw, 3 /
8
-16 x 1¼ 1
16 80017A Bolt, 3 /
8
x 2¾ 1
17 20023A Guard, Belt 1
18 80131A Screw, Carriage, ¼-20 x ¾ 1
19 85702A Screw, ¼-20 x ¾ 1
20 60384A Bracket, Latch 1
21 68393A Tube, Latch 1
22 81102A Nut, ¼-20 ESNA 2
23 60366A Pulley, Fan 1
24 920196 Nut 1
25 877304 Ring, Retaining, Internal 1
26 51111A Bearing, Ball 2
27 915561 Key 2
28 85812A Screw, 5 /
16
-18 x 7 /
8
3
29 171101 Nut, 3 /
8
-16 Flange 1
30 23301A Fan 1
31 61602A Collar 1
32 902567 Beaing, Ball 1
33 20026A Cover, Fan 1
34 920110 Nut, 5 /
16
-18 1
Ref No. Part No Description Qty
35 60370A Shaft, Fan 1
36 962870 Screw, 3 /
8
-16 x 7 /
8
Button 1
37 87000A Washer 1
38 51215A Bearing, flange 1
39 87052A Washer 2
40 61600A Clip-dust 1
41 60368A Lever, Belt Tensioning 1
42 86111A Screw, ¼-20 x ½ 1
43 980657 Washer, Lk ¼ Std 1
44 60397A Cover, Dust Throat 1
45 85517A Screw, 10-24 x ½ 13
46 60392A Bumper, Front 1
47 51219A Rivet, Nylon 3
48 962727 Screw, 8-32 x ½ 2
49 52338A Latch, Draw 1
50 87700A Screw, ¼-20 x ½ 5
51 60386A Handle, Mainframe 1
52 51093A Cam, Belt Release 1
53 60482A Spacer 1
54 962565 Screw 1
55 60475A Bolt, Adjustment 2
56 962216 Screw, 3 /
8
-16 x 1¼ 1
57 Ref. Assembly, Motor 1
58 51039A Belt, Fan 1
59 51024A Belt Drive 1
60 52420A Cover, Lever 1
61 930093 Rivet, 1 /
8
x 5 /
16
2
62 74045A Plate, Danger 1
63 50954A Bag 1
* 64 10332A Tool Kit (includes * items) 1
* 51273A 3 /
32
Hex Key (incl. in #64) 1
* 51274A 7 /
32
Hex Key (incl. in #64) 1
* 51347A Pouch (incl. in #64) 1
* 59810A Wrench 9 /
16
x 7 /
16
(incl. in #64) 2
