21

ASSEMBLY OF THE FRONT STABILIZER

Step 1

Step 2

22

ASSEMBLY OF THE FRONT GEAR BOX ONTO CHASSIS

30403

3x8mm

40199

30341

40029

3x3mm

3X18mm

94006
3x18mm
Hex Screw

.....x2

94033
M3x3
Set Screw

.....x2

94035
M3x8mm
Set Screw

.....x2

94040
3x8x0.8mm
Washer

.....x2

94002
3x8mm
Hex Screw

.....x2

94019
3x10mm
Flat Head Hex Screw

94027
4x16mm
Flat Head Hex Screw

94026
4x12mm
Flat Head Hex Screw

3x8mm

3x8mm

34027

3x8mm

4x16mm

3x25mm

4x16mm

3x10mm

4x12mm

30684

30240

.....x2

.....x4

.....x2

*Makes two rods for left and right
hand-side

8

94023
3x25mm
Flat Head Hex Screw

.....x2
