OFNA Racing Ultra LX 2 User Manual

Page 10

ASSEMBLY OF THE FRONT SUSPENSION ARMS

Step 1

Step 2

Step 1

Step 2

Assemble both right and left side.

*Approx. 9.5mm

Step 1

Step 2

4x10mm

2.5mm

36020

36861

36850

36690

3x25

3mm

36640

36171

3x8mm

3x8x0.8mm

34027

3x8x0.8mm

3x3mm

3x18mm

30341

30403

3x8mm

40199

40029

36011

36170

36870
4x10
Set Screw

.....x2

90020
2.5mm E-Ring

.....x4

36850
5x35mm
Turnbuckle

.....x2

36170
3mm Arm Shaft

.....x2

94008
3x25mm
Hex Screw

.....x2

94041
3mm Nylon Nut

.....x2

90021
3mm E-Ring

.....x8

36640
4mm Arm Shaft

.....x2

36171
4mm Arm Shaft

.....x2

94006
3x18mm
Hex Screw

.....x2

94002
3x8mm
Hex Screw

.....x2

94040
3x8x0.8mm
Washer

.....x2

94033
M3x3
Set Screw

.....x2

94035
M3x8mm
Set Screw

.....x2

*Makes two rods for left and right
hand-side

36850
7mm Ball

.....x2

Assemble both right and left side.

*Insert the front drive shaft into
cap joint before assembly.
