OFNA Racing Ravager - Manual (Page 21)

40028
Center Drive
Shaft (93mm)
40028
Center Drive
Shaft (93mm)
4x12mm
Flat Head
Screw
3x25mm
Cap Screw
3mm
Nylon Nut
40018
Center Chassis
Brace
( Rear )
40018
Center Chassis
Brace
( Front )
3x12mm
Screw
4x16mm
Flat Head
Tapping Screw
4x16mm
Flat Head
Tapping Screw
2.6x10mm
Flat Head
Tapping Screw
3mm
Nylon Nut........1
3 x 12mm
Tapping Screw........3
3 X 25mm
Cap Screw.........1
4 x 12mm
Flat Head Screw..........2
4 x 16mm
Flat Head
Tapping Screw..........4
ASSEMBLY OF THE CENTER DIFF.
Assembly of the center stiffener onto chassis
OPTION: #49015 CNC ALUM.
FRONT & REAR CHASSIS
BRACES
e Scr w
e C men
t
94026
94026
94004
35313
90019
94027
94027
94027
94004
90019
35313
