Assembly of the front stabilizer – OFNA Racing Ravager User Manual

Page 12

background image

3X12mm
Tapping Screw

* Insert the front bumper
before assembly.

3x8mm
Set Screw

40029
Stabilizer
Ball End

40029
Stabilizer
Ball End

30401
6mm
Ball End

3x20mm
Screw

3x20mm
Screw

3x3
Set Screw

3x3
Set Screw

40019
Stabilizer

3x10mm
Flat Head
Tapping Screw

3x10mm
Flat Head
Tapping Screw

3x3mm
Set Screw

40018
Stabilizer
Mount Plastic

40013
Front
Bumper

40064
Chassis
Hard Coated

4x16mm
Flat Head
Tapping Screw

4x16mm
Flat Head
Tapping Screw

30341
Stabilizer Ball

30341
Stabilizer Ball..........2

ASSEMBLY OF THE FRONT STABILIZER

3 x 10mm
Flat Head
Tapping Screw........2

4 x 16mm
Flat Head
Tapping Screw..........4

3 x 20mm
Screw ......................2

3 x 12mm
Tapping Screw..........1

3 x 3mm
Set Screw..............4

94033

94033

94007

94007

94007

94033

94019

94004

94019

94033

94019

94027

94027

94004

94027

94035
