OFNA Racing Ravager - Manual (Page 14)

4x20mm
Screw
( Small Head )
ASSEMBLY OF THE WING STAY
40027
Rear
Body Mount
( Take the plastic part from #40027Rear Win Stay Set. )
40026
Rear
Shock Tower
3x12mm
Tapping Screw
3mm
Nylon Nut
40027
Wing Mount
40027
Wing Mount
*Insert the 3mm nylon nut
before assembly.
3x20
Tapping Screw
3x20
Tapping Screw
40027
Wing Stay
( Left )
40027
Wing Stay
( Right )
40027
Wing Mount
40027
Wing Mount
40027
Wing Stay
Post
3x12mm
Tapping Screw
4x15mm
Tapping Screw
( Small Head )
4x15mm
Tapping Screw
( Small Head )
3 x 20mm
Tapping Screw............6
4 x 15mm
Tapping Screw
( Small Head )............2
4 x 15mm
Tapping Screw
( Small Head )............4
3mm
Nylon Nut........2
3 x 12mm
Tapping Screw........3
OPTION: #49004 CNC 7075 REAR
SHOCK TOWER
OPTION: #49023 CNC ALIM.
POSTS, WING MOUNT
94007
35313
94007
94004
94004
94011
94011
94012
94011
94007
35313
94004
