OFNA Racing Picco Offroad User Manual

Page 7

ASSEMBLY OF THE FRONT AND REAR DIFF.

ASSEMBLY OF THE CENTER DIFF.

Step 1

Step 2

Step 1

Step 2

Step 1

Step 2

4x4 mm

40009

36053

Oil

Builds two differentials for front and rear.

.....X8

30776
4x10mm Washer

30773
4mm
Cross Pin

.....X4

. O l

Diff i

40011

3x12mm

94020
3x12mm

Flat Head Hex Screw

.....X8

Builds two differentials for front and rear.

*Put the Diff. Oil #3000 for front and the #1000 for rear
*Fill the Diff. case to approx. 80% with the Diff. Oil

Oil

4x4mm

40005

40009

Oil

Tight the diff screws in this order.

40513

40003

49032

40006

36053

40513

40010

40001

Tighten

40003

40513

40009

36053

40005

40513

30773

30776

40009

40010

40513

36053

40006

40010

Oil

36053
8x16mm Ball Bearing

.....x4

94034
4x4mm
Set Screw

.....x2

40009
P6 O-Ring

.....x4

40010
2.5x13.8mm Pin

.....x4

36053
8x16mm Ball Bearing

.....x2

94034
4x4mm
Set Screw

.....x1

40009
P6 O-Ring

.....x2

40010
2.5X13.8MM PIN

.....x2
