Assembly of the radio tray onto chassis, 34 assembly of the steering servo and steering rod – OFNA Racing Picco Offroad User Manual

Page 18

background image

35

36

12

34

ASSEMBLY OF THE RADIO TRAY AND STICK PACK BATTERY

40130

94003
3x10mm
Hex Screw

.....x2

Step 1

Step 2

40130

3x10mm

3x10mm

40130

ASSEMBLY OF THE RADIO TRAY ONTO CHASSIS

3x10mm

94019
3x10mm
Flat Head Hex Screw

.....x8

3x10mm

94004
3x12mm
Hex Screw

.....x1

3x12mm

3mm

3mm
Nut

.....x1

34

ASSEMBLY OF THE STEERING SERVO AND STEERING ROD

*Approx. 18.5mm

1:1

30342

30401

30403

30401

30661

3x10mm

30403

* Use the screw
provided with
your servo .

94003
3x10mm
Hex Screw

.....x1

.....x2

30403
6mm Ball

37410

37410

Battery Case
