11

32

ASSEMBLY OF THE RADIO TRAY AND RECEIVER BOX

Step 1

Step 2

40047

10282

40047

40047

30560

3x10mm

* Use the screw
provided with
your switch .

2x10mm

2x25mm

Receiver

Switch

2x10mm
Tapping Screw

.....x2

2x25mm
Screw

.....x1

3x12mm

33

94003
3x10mm
Hex Screw

.....x1

94004
3x12mm
Hex Screw

.....x2

31

32

Step 1

94003
3x10mm
Hex Screw

.....x6

.....x8

94004
3x12mm
Hex Screw

.....x8

3x10mm

40047

40047

3x12mm

40031

3x8mm

ASSEMBLY OF THE RADIO TRAY

3x8mm

3x8mm

3x8mm

Step 2

3x10mm

3x10mm

40031

94040
3x8mm Washer

49054

3x12mm

3x12mm

ASSEMBLY OF THE REAR GEAR CASE ONTO CHASSIS

40028

94026
4x12mm
Flat Head Hex Screw

.....x2

*Insert the drive shaft into
the cap joint before assembly
rear gear box onto chassis.

4x12mm

4x16mm

94027
4x16mm
Flat Head Hex Screw

.....x4
