OFNA Racing Picco Offroad User Manual
Page 24
51
52
ASSEMBLY OF THE WING
ASSEMBLY OF THE TIRES AND WHEELS
18
Step 1
Step 2
IN
S
TA
N
T
G
L
U
E
Apply instant glue into the groove of the wheel.
86082
86056
81095
.....x2
.....x2
94004
3x12mm
Hex Screw
94041
3mm
Nylon Nut
3x12mm
40027
3mm
3mm
53
ASSEMBLY OF THE TIRE ONTO FRONT KNUCKLE AND REAR HUB
Assembly for both right and left side.
Tire and Wheel assembly.
40550
.....x4
40550
Wheel Nut
40550
40550
40550
16015
Drill two 7mm holes for mounting.
Body Reamer (Not included)
40027
