OFNA Racing Mutilator Pro RTR 32 - Manual (Page 8)

5 ASSEMBLY OF THE FRONT SHOCK STAY
94004
3X12mm .......X4
Hex Screw
94010
4X12mm .......X4
Hex Screw
94012
4X20mm ........X2
Hex Screw
35313
M3 ........X2
Nylon Nut
35314
M4 ........X2
Nylon Nut
90018
3X25mm ........X2
Screw
3X12mm
4X12mm
4X20mm
M4
Nylon Nut
4X12mm
3X12mm 3X25mm
M3
Nylon Nut
40116
40531
40117
40117
S cr
ew
C em
en
t
6 ASSEMBL OF THE KNUCKLE ARMS Y
40141
40526
40527
40527
Knukcle Arm
Bushing
36055
4X4mm
........X2
........X4
........X4
........X4
........X2
40528
King Screw
35314
M4
Nylon Nut
40536
2.5X16.8mm
Pin
94034
4X4mm
Set Screw
Right side
36053
40520
Assembly for both right and left side
40528
M4
M4
36053
Step 1 Step 2
Step 3 Step 4
3
*Insert the knuckle
arm bushing before
assembly.
*Put the ball bearing
into knuckle arm.
Tighten
