46 assembl of the rear shock absorber y – OFNA Racing Mutilator Pro RTR 32 User Manual
Page 24
3X8mm
3mm
3X20mm
Apply instant glue into the groove of the wheel.
I
N
N
S
TA
T
G
U
E
L
80007
86104
40550
Tire and wheel assembly
46
ASSEMBL OF THE REAR SHOCK ABSORBER
Y
Assembly for both right and left side
........X2
94041
3mm
Nylon Nut
........X2
94007
3X20mm
Hex Screw
47
ASSEMBL OF THE TIRES AND WHEELS
Y
48
ASSEMBL TIRE ONTO FRONT KNUCKLE AND REAR HUB
Y
19
Step 1
Step 2
Step 3
