Page 20

ASSEMBLY OF THE RECEIVER BOX

* Use the screw provided
with your radio

10280
Switch Cover

Switch, Provided by Radio

40047
Receiver Box

40047
Receiver Box
Cover

40047
Receiver Box

2x10mm
Tapping Screw

40898
2x25mm
Screw

Receiver

Battery Case,
Provided by
Radio

30560
Antenna
Pipe

94003
3 x 10mm
Tapping Screw..........1

3x10mm
Screw

2 x 25mm Screw.....1

2 x10mm
Tapping Screw..........2

Option:
10212
Hump Pack
Battery

*Use the original battery
case or rechargeable
hump pack battery.

* You must add padding for radio
and battery once lid is closed.
Do not let radio and/or battery be
loose in box.

40028
Center Drive
Shaft (93mm)

4x12mm
Flat Head
Screw

3x25mm
Cap Screw

3mm
Nylon Nut

40018
Center Chassis
Brace
( Rear )

40018
Center Chassis
Brace
( Front )

3x12mm
Screw

4x16mm
Flat Head
Tapping Screw

2.6x10mm
Flat Head
Tapping Screw

35313
3mm
Nylon Nut........1

94004
3 x 12mm
Tapping Screw........3

90019
3 X 25mm
Cap Screw.........1

94026
4 x 12mm
Flat Head Screw..........2

94027
4 x 16mm
Flat Head
Tapping Screw..........4

ASSEMBLY OF THE CENTER DIFF. ONTO CHASSIS

ASSEMBLY OF THE CENTER STIFFENER
ONTO CHASSIS

OPTION:
49015
CNC Alum. Chassis Brace Set

ASSEMBLY OF THE STONE GUIDE

40046
Stone Guard

3x10mm
Screw

Assembly of the right and left hand side
are the same.

3 x 10mm
Tapping Screw..........6

OPTION:
Stone Guard
Yellow . 40078
Red . 40079
Lime . 40080
Blue . 40081
Black . 40046
