Page 17

ASSEMBLY OF THE SERVO SAVER

M3 Nut

* Put the 3mm
nut before assembly.

40031
Servo Saver
Horn A

40095
Servo Saver
Connecting Plate,
Orange

6x10mm
Plastic
Bushing

Servo Saver
Horn C

4x8mm
Plastic flange
Bushing

40037
Steering Plate
Hex Screw

40035
Servo Saver
Alum. Axle
Tube

40031
Servo Saver
Horn B

40033
Servo Saver
Spring

40034
Servo Saver
Spring Tension
Adjuster

40036
servo Saver
Post

40036
Servo Saver
Post

40074
6x10mm
Ball bearing

35313
M3 Nut..........1

4x10mm
Screw..........2

* Take the 4x8mm Plastic Flange bushing
and Plastic Bushing from servo saver plastic
parts tree

OPTION: #49014 CNC BALL

BEARING AXLE TUBE

Option:
40073
4x8mm
Ball bearing
flange

40037
Steering Plat
Hex Screw....... 2

Option:
40074
6x10mm
Ball bearing

94027
4 x 16mm
Flat Head
Tapping Screw..........4

94027
4 x 16mm
Flat Head
Tapping Screw

40064
Chassis

4x10mm
Flat Head
Screw

4x10mm
Screw

4x15mm
Tapping Screw

40027
Front Body
Post

3x12mm
Screw

* Assembly the front body post
before assembly the Front Plate.

ASSEMBLY OF THE SERVO SAVER ONTO THE CHASSIS

40018
4x56mm
Turnbuckle

36850
7mm Ball

36700
Steering
Ball End

35313
3mm
Nylon Nut

40039
3mm Tapper
Washer(Alum.)

40039
Alum. Tapper
Washer................4

3x15mm
Flat Head
Screw

ASSEMBLY OF THE FRONT STEERING ROD

35313
M3
Nylon Nut..........2

94021
3 x 15mm
Flat Head
Screw..........4

40030
Front Plate

94009
4x10mm
Screw..........2

94004
3 x 12mm
Tapping Screw..........1

94011
4 x 15mm
Tapping Screw
( Small Head )............2

94026
4 x 10mm
Flat Head Screw..........2

Assembly of the right and left hand side
are the same.

* Anticlockwise mark.

35.5mm

* Made two steering rods for left and right hand side.

OPTION:
49005
CNC 7075 Alum. Front Plate
49019
Graphite Front Plate

0 10 20 30 40 50
