Page 11: Assembly of the front upper arms, Assembly of the front knuckle arms

background image

94004
M3x12
TP Screw

M4x15
TP Screw

4mm
Nylon Nut

ASSEMBLY OF THE FRONT KNUCKLE ARMS

ASSEMBLY OF THE FRONT SHOCK TOWER

OPTION: 49003
CNC 7075 Alum. Shock Tower

40014
Front
Shock Tower

L

L

36053
8x16x5mm
Bal lbearing

36053
8x16x5mm
Bal lbearing

90026
5mm
Set Screw

36054
Alum.
Wheel Hub 8mm

36055
2.5x17mm
Pin

S

c

re

w

C

e

m

e

n

t

40103
Front
Knuckle Arm

40103
Front
Knuckle Arm

* "R" for right hand
side.

40105
8mm CVA Joint
(Long/Front)

40105
8mm CVA Joint
(Long/Front)

36053
8x16x5mm
Ball bearing

36053
8x16x5mm
Bal lbearing

90026
5mm
Set Screw

36054
Alum.
Wheel Hub 8mm

36055
2.5x17mm
Pin

Sc

rew

Ce

me

nt

Assembly of the left and gight hand side
are the same.

Assembly of the left and gight hand side
are the same.

ASSEMBLY OF THE FRONT LOWER ARMS

36870
4X10mm
Set Screw

36870
4X10mm
Set Screw

* A 4 x 10mm set screw is used
to adjust the ride height.

2mm

40102
Front
Lower Arm

40102
Front
Lower Arm

40104
10mm
Steering Ball

4014
10mm
Steering Ball

40104
10mm
Steering Ball

40104
10mm
Steering Ball

40101
Upper Arm
Ball End

40101
Upper Arm
Ball End

*Notice the direction
of the steering ball.

*Notice the direction
of the steering ball.

90020
2.5mm
E-Ring

90020
2.5mm
E-Ring

36170
Arm Shalf
3mmt

Assembly of the right and left hand side
are the same.

Assembly of the right and left hand side
are the same.

ASSEMBLY OF THE FRONT LOWER ARMS

40023
Lower Arm Shaft (4mm)

90021
3mm
E-Ring

90021
3mm
E-Ring

ASSEMBLY OF THE FRONT SUSPENSION ARMS

36860
5x40mm
Turnbuckle

ASSEMBLY OF THE FRONT UPPER ARMS

40104
4x16mm
Cap Screw

40104
4x16mm
Cap Screw

Sc

rew

Ce

me

nt

Sc

rew

Ce

me

nt

* Insert the drive shaft
into cap joint before assembly.

40101
Front
Upper Arm
Ball End

40101
Front
Upper Arm

(Right)

(Left)

Caster
Adjuster

* Insert the caster adjuster
into upper arm.

10mm

0 10 20 30 40 50

mm
