Assembly of the front stabilizer, Assembly of the wing stay – OFNA Racing 9.5 Violator User Manual

Page 12

94004
3X12mm
Tapping Screw

* Insert the front bumper
before assembly.

40013
Front
Bumper

40064
Chassis

30341
A34B
Stabilizer Ball..........2

ASSEMBLY OF THE FRONT STABILIZER

94019
3 x 10mm
Flat Head
Tapping Screw........2

94027
4 x 16mm
Flat Head
Tapping Screw..........4

94007
3 x 20mm
Screw ......................2

94004
3 x 12mm
Tapping Screw..........1

94033
3 x 3mm
Set Screw..............4

94007
3x20mm
Screw

94033
3x3
Set Screw

40019
Stabilizer

94019
3x10mm
Flat Head
Tapping Screw

40018
Stabilizer
Mount Plastic

3x8mm
Set Screw

40029
Stabilizer
Ball End

30401
6mm
Ball End

30341
Stabilizer Ball

40029
Stabilizer
Ball End
(Long)

94012
4x20mm
Screw
( Small Head )

ASSEMBLY OF THE WING STAY

40027
Rear
Body Mount

( Take the plastic part from #40027Rear Win Stay Set. )

49038
Rear
Shock Tower, Orange

3x12mm
Tapping Screw

35313
3mm
Nylon Nut

40027
Wing Mount

*Insert the 3mm nylon nut
before assembly.

3x20
Tapping Screw

94007
3x20
Tapping Screw

40027
Wing Stay
( Left )

40027
Wing Stay
( Right )

40027
Wing Mount

40027
Wing Stay
Post

94004
3x12mm
Tapping Screw

94011
4x15mm
Tapping Screw
( Small Head )

3 x 20mm
Tapping Screw............6

4 x 15mm
Tapping Screw
( Small Head )............2

4 x 15mm
Tapping Screw
( Small Head )............4

3mm
Nylon Nut........2

3 x 12mm
Tapping Screw........3

OPTION: #49004 CNC 7075
REAR SHOCK TOWER

OPTION: #49043 CNC ALIM.

POSTS, WING MOUNT, ORANGE

4x16mm
Flat Head
Tapping Screw
