Memory Edit page
The Memory Edit page stores and recalls the 16 NM 84
Memories. Memory Recall Port Transmit (MRP Tx) and MRP
Receive (MRP Rx) are also set in this page.
Conceptually, the NM 84 contains 17 Memories; Memory
zero contains the current settings which are always displayed
on the LCD screen. Therefore, all changes made from the
front panel alter the current settings – Memory zero. Once the
desired settings are reached using the Edit pages, Memory
zero (the current settings) can be stored into one of the 16
Memory locations. Additionally, recalling one of the 16 stored
Memories places that Memory’s contents into Memory zero
for display, viewing, and further editing if needed.
The number of the most recently recalled Memory, 1
through 16, is displayed on the top left of the Mem LCD page.
An asterisk (*) appears to the right of this Memory number
when the current settings no longer matched the displayed
Memory’s contents. This indicates a change to the NM 84
settings has been made since the last Memory was recalled.
To store the current settings, move the cursor under Store,
use the DATA wheel to display the Memory number to store
the currents settings into, then press the EXE button.
To recall, move the cursor under Recall, use the DATA
wheel to display the Memory number to recall from, then
press the EXE button which overwrites the current settings.
The NM 84 provides up to 16 MRP (Memory) data
transport channels which are asynchronously transported over
the CobraNet network to other NM devices which are set to
“listen” to the corresponding MRP channels. The MRP Tx
(MRP Transmit) parameter can be set to one of the 16 MRP
channels or Off. The Off setting – you guessed it – turns off
MRP transmission. The numeric settings – integers 1 through
16 – tell the NM 84 to Transmit its current MRP contact
closure status over the network to other NM devices that are
set to receive the corresponding MRP channel. This allows
other Rane NM devices to use remotely located NM device’s
MRP switch states to change Memories.
The MRP Rx (MRP Receive) parameter can be set to
Local, Off or integers 1 through 16. The Local setting tells
the NM 84 to scan its own rear panel Memory Recall Port for
switch closures. Off turns off the MRP completely and 1
through 16 sets the desired MRP channel to “receive from” or
“listen to.”
The following parameters are stored in each Memory:
 All Mic In settings: Mode, Mute, Trm, Gain, 48V, Flt, Lim
 All Monitor Out settings: Source, Bndl/Mic, AudCh
 All Serial, RS-232, settings: Baud, 232 Rx, 232 Tx
Therefore, parameters found in the NetTx, Mem and
Config edit pages are not stored in Memories. The intent of
disallowing Memories to alter the Network Transmit settings,
for example, is to keep the familiarity of a radio broadcasting
paradigm relevant to CobraNet network Bundles. Thus,
sticking to always transmitting audio over the same Bundles
while using Memories to re-route to the desired channels,
helps make things more easily managed. In other words,
always transmit on the same Bundles (i.e., fixed radio station
transmission) but “tune in” to the desired Bundle and Audio
Channel to receive (Monitor) the audio needed.
Parameter Range
Store Integers 1 through 16
Recall Integers 1 through 16
MRP Tx (MRP transmit) Off, integers 1 through 16
MRP Rx (MRP Receive) Local, Off, integers 1 through 16
Serial Edit page
The Serial Edit page configures the RS-232 port. The
Baud parameter must be set to the desired baud rate for the
device used with the RS-232 port. Typical choices up to
38,400 baud are found. See the complete list below.
The NM 84 provides up to 255 serial data channels which
are asynchronously transported over the CobraNet network to
other NM devices set to receive and transmit over correspond-
ing serial channels. The 232 Tx and 232 Rx parameters set
these respective transmit and receive serial channels for
transport of the RS-232 port’s data. Be certain to use one
channel for transmit such as 1, and a different channel to
receive, such as 2. We know that you know that 1 is different
than 2, but this is of course necessary, since RS-232 requires a
different transmit and receive pair and therefore independent
channels.
Another important thing to remember as far as the 232
port’s physical connections go, be sure you review the
required connector sex, male or female, when transporting
232 around. All NM devices contain a female RS-232 (DB-9)
connection on the rear.
For example, when transporting Rane’s RW 232 protocol
from a computer to an NM 84, over the network to another
NM device, the cabling should be as follows:
The end of the cable at the computer connection will be
female – since the DB-9 on a computer’s COM ports are male.
The other end of the cable will be male so one can connect it
at the initial NM 84 device. At the second NM device, the rear
panel DB-9 is female, thus requiring a male on the end of the
second cable. The DB-9 Input on RW 232 devices is a female.
Therefore, a male-to-male gender bender is required on the
RW 232 Input side of the second cable to permit using a
standard serial cable.
Parameter Range
Baud 600, 1200, 2400, 4800, 9600,
19200, 38400
232 Rx (232 Receive) Off, integers 1 through 255
232 Tx (MRP transmit) Off, integers 1 through 255
Mem 1* Store Recall MRP Tx MRP Rx
1 1 Off Off
Memory Edit Page
Serial: Baud 232 Tx 232 Rx
38400 Off Off
Serial Edit Page
